Downloads

Download our technical drawings and enter your customer specifications. Send your completed drawing to info@tichalmers.co.za.

• Bolt size and length;
• Shield length;
• Hole diameter and minimum hole depth;
• Maximum fixture thickness;
• Recommended tension load; and
• Pull out load.

Anchorfix PSC

Polyester resin for use in concrete

SVM-PSC is general purpose non-cracked resin, with a relatively short cure time.

Anchorfix PSF

Polyester resin for use in concrete and lightweight substrates

SVM-PSF is general purpose resin, for solid and hollow structures with a relatively short cure time.

• Anchor product;
• Material type (Gr5.8, Gr8.8, SS, Rebar and threaded socket anchor);
• Substrates (solid/aerated concrete, clay/silicate brick and blocks);
